These Kinugawa Japan CT26 turbos are designed as a bolt on upgrade for the CT26 as used on the 12HT Landcruiser (1985-1989).
Specifications:
*Suit 85-89 Toyota Landcruiser.
*Compressor wheel: 60 / 76 mm (Garrett 60-1 comp wheel)
*Turbine Wheel: 51.9 / 67.9 mm
*Journal Bearing
*Oil and water cooled
*Actuator Pressure 1 Bar / 15 psi default
*Supplied with fitting kit including: Oil Feed and oil return gaskets, water feed and water return gaskets, Turbine Inlet Gasket, Turbine Outlet gasket
